Azure Local Deployment Failed - How do I recover the nodes to try again?

Hi Mike Jackman,

It sounds like you're facing quite a challenge with your Azure local deployment getting stuck. I understand how frustrating it can be after investing such a significant amount of time. Here are a few steps you can take to help reset your nodes and possibly avoid starting over.
Restart the Device Management Service

Restart-Service DeviceManagementService
This service manages device provisioning and status updates with Azure Stack HCI. Restarting it helps refresh the device state, particularly in the Azure portal or Windows Admin Center. After this, you can check Get-ClusterNode, Get-VMNetworkAdapter, or look for stale provisioning states.

Check for Unexpected VM Switches

During cluster setup, unexpected or auto-created switches (e.g., ConvergedSwitch(managementcompute)) can interfere with expected network layout.

Get-VMSwitch

• Remove unexpected ones: Remove-VMSwitch -Name "ConvergedSwitch(managementcompute)" -Force
  https://learn.microsoft.com/en-us/powershell/module/hyper-v/remove-vmswitch?view=windowsserver2025-ps

Restart Deployment via the Azure Portal

Tthis can work if the node is still showing in the Azure portal under Arc-integrated infrastructure. Go to Azure > Azure Stack HCI > Your cluster. Use "Customize" > Uncheck nodes that were already attempted or failed.Revalidate and redeploy.

• Note: You can only do this if Azure Arc agent is still running and reporting correctly on the nodes.

Repair the Nodes

$Cred = Get-Credential

Repair-Server -Name "NodeName" -LocalAdminCredential $Cred

It is a valid command if you're using Windows Admin Center (WAC) or Azure Stack HCI deployment scripts.

This command repairs a node that failed during deployment or has partial configuration (like AD join but no cluster role). It helps avoid full reimaging.

Monitor Operation Progress

$ID = "<Operation ID>"

Start-MonitoringActionplanInstanceToComplete -actionPlanInstanceID $ID

• This is part of the Azure Stack HCI "action plan" automation framework.
• It’s correct in environments using Azure Edge Stack HCI deployments, especially when runbooks or orchestration are involved.
• Helps track and wait for long-running operations (like cluster creation, SDN config, etc.).

Document for reference: https://learn.microsoft.com/en-us/azure/azure-local/manage/repair-server?view=azloc-24113- What version of Azure you're currently using, and did you notice any issues or errors during the validation stage?

• Are there any specific error messages you're receiving, either during the booting process or when trying to access the nodes?

Let me know if you have any further queries!

If the information is helpful, please click "upvote" to let us know!

I appreciate the effort put into this response. Unfortunately I already tried everything here and read all documents cited. None worked. I am hour 5 into reinstalling Azure Stack HCI on all nodes. This really is the worst.

if deployment fails post-AD join but pre-cluster config, the only supported remediation path is to reimage and use Repair-Server.

Hello Mike Jackman,

When the nodes successfully join Active Directory, the operating system applies domain policies, firewall rules, and trust settings that harden the configuration. If the deployment fails at this point — due to a timeout, orchestration crash, or partial provisioning — the node becomes stuck in an inconsistent state. It will autoboot into a half-provisioned environment and block retry attempts, such as deleting virtual switches / restarting the deployment from WAC / running repair scripts without cleanup

In the official Microsoft Learn article Repair a node on Azure Local, Microsoft provides detailed guidance for what to do when a node ends up in a broken or failed state. It states that “Repairing a node reimages a node and brings it back to the system with the previous name and configuration.”

This tells us that recovery assumes a fresh OS install.

It also explains that only the system volume is deleted and newly provisioned during deployment. which confirms that system cleanup, not rollback, is the supported path. Under node replacement, it allows Current node (reimaged)” scenarios, showing that reusing hardware is supported only after a clean OS install. Therefore, recovery is expected to happen only via reimage + repair. The use of the command Repair-Server -Name "<Node>" assumes that the OS has already been freshly installed and re-registered with Azure Arc before invoking the repair process.

If you're still mid-deployment and haven't reimaged yet, you can try the following manual cleanup approach to bring the nodes back into a usable state

Clear cluster and deployment state

Stop-Service ClusSvc -Force

Remove-Item -Recurse -Force "C:\Windows\Cluster"

Remove-Item -Recurse -Force "C:\ProgramData\Microsoft\Windows\Cluster"

Remove-Item -Recurse -Force "C:\ProgramData\Microsoft\AzureStackHCI\HciDeployment" -ErrorAction SilentlyContinue

If available the do a

Clear-HCIConfigurationState

then check and remove stuck network switches

Get-VMSwitch | Remove-VMSwitch -Force

If blocked then do a

Disable-NetAdapterBinding -Name "vEthernet (ConvergedSwitch*)" -ComponentID ms_tcpip

Disable-NetAdapterBinding (NetAdapter) | Microsoft Learn

From your domain controller, delete the node’s computer object and flush DNS entries

If registered with Arc do a azcmagent disconnect

Install the same version of the Azure Stack HCI OS on the node. Then register the node with Azure Arc using the same resource group, subscription and region and assign the appropriate roles (Azure Local Device Management, Key Vault Secrets User, etc.)

Run the repair commands from another working node in the cluster

$cred = Get-Credential

Repair-Server -Name "<NodeName>" -LocalAdminCredential $cred

You can even monitor the operation

Start-MonitoringActionplanInstanceToComplete -actionPlanInstanceID "<OperationID>"

verify the same using Get-VirtualDisk | Get-StorageJob

If no output, storage rebalance is complete

I stayed up until 4am, reimaged all the hosts and started completely from scratch. Same behavior, stuck after the nodes are adopted into the AD. Unless someone has an idea better than spending 6 hours to reimage all the hosts and get them in Arc again, I do believe Proxmox is my future.
